Diamond wire saws for granite block squaring and profiling
Product features
1. It can cut the block with the thickness of 2.3M.2. It can cut accurately with small inter-space.
3. Reliable cutting and can change the cutting technology according to the stone types.
4. Compare to the blade cutting, it makes lower cutting noise.
5. The profile wire saw can process a variety of special-shaped stones, and the cutting angle and orientation can be adjusted arbitrarily, making the stone more shapeable.
Cutting
Polish&Drill
+
Mining
Machines
Product description
1. It can cut the block with the thickness of 2.3M.2. It can cut accurately with small inter-space.
3. Reliable cutting and can change the cutting technology according to the stone types.
4. Compare to the blade cutting, it makes lower cutting noise.
5.The profile wire saw can process a variety of special-shaped stones, and the cutting angle and orientation can be adjusted arbitrarily, making the stone more shapeable.
Reference: Specification and performance parameters of diamond wire-saws
| Specification(mm) | Beads/m | Reinforcement | Use |
| Φ11.5 | 37 | Plastic | Granite Squaring |
| Φ11 | 37 | Plastic | Granite Squaring |
| Φ8.9 | 37 | Plastic | Granite Profiling |
| Φ8.2 | 37 | Plastic | Granite Profiling |
Reference: Cutting material and parameters of diamond wire-saws
| Cutting material | Line speed (m/s) | Efficiency (m2/h) | life (m2/m) |
| Class 1-2 | 26-32 | 1.5-2.5 | 30-55 |
| Class 3-4 | 26-30 | 1.2-2.0 | 15-35 |
| Class 5 | 26-28 | 0.8-1.6 | 15-25 |
